MWDC E8A Powder Descriptions
MWDC E8A Powder is one product among our dielectric microwave ceramic powders. Microwave Dielectric (MWDC) is a type of ceramic material employed in microwave frequency band circuits.
It is primarily used in UHF and SHF bands (300 MHz to 300 GHz with wavelengths between 0.1 mm and 1 m). It performs one or more functions.
It is suitable for the manufacture of various microwave devices. These include frequency‐stabilising oscillators, filters and discriminators used in electronic countermeasures, navigation, communication, radar, domestic satellite direct television receivers and mobile telephones. The devices meet the requirements for miniaturisation, integration, high reliability and low cost in microwave circuits.
Specifications of the MWDC E8A Powder
Microwave Properties
|
Resonant Frequency (GHz)
|
11.4
|
Dielectric Constant
|
8.2
|
Quality Factor (GHz)
|
>35 000
|
Τf (ppm/℃) (-35 ~ 85℃)
|
±15.0
|
Sintering Temperature Range
|
1320-1360℃
|
MWDC E8A Powder Microstructure

MWDC E8A Powder Applications
-Dielectric Resonator/Filter
-Antenna
-Substrate for MIC
-Cellulose and Paper
-Single-layer Capacitor for HF, etc.
