Description:
The nitrogen production method using adsorption processes in nitrogen generators is applied in industrial installations for the production of high-purity nitrogen. The principle of the pressure swing adsorption nitrogen generator is based on the differing adsorption rates of the carbon molecular sieve for various gas mixture components. Under defined pressure conditions, the carbon molecular sieve adsorbs oxygen and releases nitrogen, thereafter expelling the oxygen into the ambient air while collecting the nitrogen. By repeating this procedure, nitrogen with a purity of 99.99% is generated.

Advantages of the PSA Nitrogen Generator:
- High purity: Produces nitrogen at a purity of 99.99%
- Continuous supply: Generates nitrogen directly from air
- Safety: Eliminates the requirement for high-pressure nitrogen cylinders
- Low operating costs: Reduces expenditure by approximately 50% compared with alternative systems
- Environmentally friendly
Technical Parameters:
Type
|
Nitrogen Generator
|
Output flow (L/min)
|
0-300
|
0-500
|
Output pressure (MPa)
|
0-0.4
|
Purity (%)
|
99.99
|
Power voltage (V)
|
AC 220 50-60Hz
|
Environmental requirements
|
0-40 ℃, dust-free and without corrosive gases
|
Power consumption (W)
|
<180
|
Weight (Kg)
|
35
|
Dimensions (L x W x H) mm
|
460x290x760
|
Certification:
ISO CE
Applications:
- Carrier gas for various brands of GC (Gas Chromatography) and detectors
- Supplementary gas
- Gas for Gel Permeation Chromatographs
Packaging & Delivery:
Packaging: Wooden crate or cardboard box
Delivery: Within 15-20 days following receipt of payment
