Silver Conductive Epoxy Adhesives Description
Silver-based conductive epoxy adhesives are adhesives that exhibit a measurable level of electrical conductivity after curing or drying. They can bond various conductive materials, thereby establishing an electrical path between the joined components. In the electronics industry, the conductive adhesive is regarded as an important new material.

Conductive Silver Epoxy Adhesives
Specification
|
Result
|
Physical Properties – Cured
|
Colour
|
Silver grey
|
Hardness
|
70D to 75D
|
Tensile strength
|
6.28 N/mm [911 lb/in]
|
Elongation
|
0.30%
|
Shear strength
|
1.61 N/mm [234 lb/in]
|
Izod impact strength
|
1.7 kJ/m [0.80 ftlb/in]
|
Compressive strength
|
7.56 N/mm [1 090 lb/in]
|
Flexural strength
|
17.2 N/mm [2 500 lb/in]
|
Outgassing (Total mass loss)
|
|
at 24 h
|
7.16%
|
at 48 h
|
6.11%
|
Solderable
|
No
|
Electrical Properties – Cured
|
Volume resistivity
|
0.0174 Ω·cm
|
Dielectric loss factor & constant
|
Loss factor, constant, k'
|
at 1 MHz
|
0.012 3.01
|
Thermal Properties – Cured
|
Thermal conductivity
|
in W/mK (BTU in/(hr ft °F))
|
25 °C
|
0.903 (6.27)
|
50 °C
|
0.893 (6.20)
|
100 °C
|
0.813 (5.64)
|
Glass transition temperature (Tg)
|
55.1 °C [131 °F]
|
CTE below Tg
|
38.5 ppm/°C
|
CTE above Tg
|
101.8 ppm/°C
|
Curing Schedule
|
Air drying at 24 °C (75 °F)
|
5 hours
|
Heat curing:
|
|
65 °C/149 °F
|
15 minutes
|
90 °C/194 °F
|
12 minutes
|
125 °C/257 °F
|
7 min
|
150 °C/302 °F
|
5 min
|
Working time at 22 °C
|
10 min
|
Minimum operating temperature
|
< -55 °C (-67 °F)
|
Maximum operating temperature
|
150 °C (302 °F)
|
Conductive Silver Epoxy Adhesives Applications
Conductive silver epoxy adhesives can be used in:
- Electronics industry
- Thermally conductive coatings
- Semiconductor industry
- Machinery industry
